Panasonic Lumix S1H Series User Manual

2. Getting Started
DVQX1961 (ENG)
28
3
Insert the battery.
≥Insert the terminal end of the
battery and push until a locking
sound is heard.
0
Check that the lever A is holding the
battery in place.
4
Close the battery door.
≥Close the battery door, and move
the battery door release lever to the
[LOCK] position.

Removing the Battery
1
Set the camera on/off switch to [OFF].
2
Open the battery door.
0
Check that the card access light B is
turned off and then open the battery door.
3
Push the lever A in the direction of the
arrow and then remove the battery.
0 Ensure that no foreign objects are adhering to the inner side (rubber seal) of
the battery door.
0 Remove the battery after use.
(The battery will drain if left inserted in the camera for a long period of time.)
0 The battery becomes warm after use, during charging, and immediately after
charging.
The camera also becomes warm during use. This is not a malfunction.
0 Be careful when removing the battery as the battery will jump out.



DC-S1HGN-DVQX1961_eng.book 28 ページ ２０１９年８月８日 木曜日 午後５時５５分

Panasonic Lumix S1H Series Specifications

General

Sensor Type	CMOS
Resolution	24.2MP
Camera Type	Mirrorless
Shutter Speed	1/8000 to 60 sec, Bulb
Video Recording Format	MOV, MP4
Monitor Type	Tilting touchscreen LCD
Lens Mount	L-Mount
Dimensions	151 x 114 x 110 mm
ISO Sensitivity	ISO 100-51200 (expandable to ISO 50-204800)
Video Recording	6K/24p, 4K/60p
Image Stabilization	5-axis in-body image stabilization
Viewfinder	5.76 million-dot OLED electronic viewfinder
LCD Screen	3.2-inch 2.33M-dot touchscreen
Autofocus System	Contrast Detection with 225-area DFD
Connectivity	Wi-Fi, Bluetooth, HDMI, USB-C
Battery Life	Approx. 400 shots (CIPA standard)
Sensor Size	35.6 x 23.8 mm
Continuous Shooting	Up to 9 fps
Memory Card Slots	Dual SD card slots (UHS-II)
Battery	DMW-BLJ31
Weight	Approx. 1052g (with battery and SD card)
Log Profiles	V-Log
Storage Media	SD/SDHC/SDXC
Weather Sealing	Yes, splash and dust resistant
