Panasonic PT-DZ21KU

[PROJECTOR SETUP] menu
104 - ENGLISH
Settings
[L1] Lamp 1 will light.
[L2] Lamp 2 will light.
[L3] Lamp 3 will light.
[L4] Lamp 4 will light.
[L1/L4] Lamp 1 and Lamp 4 will light.
[L2/L3] Lamp 2 and Lamp 3 will light.
[L1/L2/L3]
Lamp 1, Lamp 2 and Lamp 3 will light.
[L1/L2/L4] Lamp 1, Lamp 2 and Lamp 4 will light.
[L1/L3/L4] Lamp 1, Lamp 3 and Lamp 4 will light.
[L2/L3/L4] Lamp 2, Lamp 3 and Lamp 4 will light.
[SINGLE]
(1 lit)
One lamp will light. (A short usage
time lamp will automatically light.)
[DUAL]
(2 lit)
Two lamps will light. (A short usage
time lamp will automatically light.)
[TRIPLE]
(3 lit)
Three lamps will light. (A short usage
time lamp will automatically light.)
[QUAD]
(4 lit)
Four lamps will light.
3) Press the <ENTER> button.
Note
z
For a set time after [LAMP SELECT] is switched,
[LAMP SELECT] cannot be switched again,
because the speed of the lamp replacement cycle
will increase. Repeatedly switching [LAMP SELECT]
in a short time will also increase the speed of the
lamp replacement cycle.
z
The colors of the items indicate the status.
Green → Current setting
Yellow → Current setting
(When there is a lamp that cannot turn on or failed
to turn on)
Red → Lamp that has failed to turn on
White → Any other status
z
When a lamp fails to turn on or has been used in
excess of 2 000 hours
*1
and a setting other than
[QUAD] is selected, that lamp is turned off and
another lamp turned on.
When a lamp fails to turn on or has been used in
excess of 2 000 hours
*1
in [QUAD], a lamp that has
not been used in excess of 2 000 hours
*1
is turned
on.
The projector enters standby mode when all lamps
have been used in excess of 2 000 hours
*1
.
z
Ensure that lamp units not to be turned on are also
installed.
z
More lamps than the specied number of lamps
light temporarily to prevent decreased illuminance
when a lamp is switched.
*1: 500 hours when the optional accessory replacement lamp
unit (for portrait mode) (Model No.: ET-LAD510P (1 pc),
ET-LAD510PF (4 pcs)) is used.
[LAMP RELAY]
The lump to be turned on can be automatically
switched by setting a day and time.
The degradation of the lamp due to continuous usage
can be reduced by automatically switching the lamp
to be turned on when using the projector continuously
for a week or more.
1) Press

to select [LAMP RELAY].
2) Press
󱽃󱽄
to switch [LAMP RELAY].

z
The time setting to switch the lamp will change
as follows each time you press the button.
[OFF] [24H] [1WEEK]
3) Press

to select [TIME].
4) Press the <ENTER> button.

z
Enters adjustment mode (the display is
blinking).
5) Press
󱽃󱽄
to select [HOUR] or
[MINUTE], and then press

to
adjust it.
(1 hour or 1 minute increments)
[00:00] [00:01] [00:59]
6) Press the <ENTER> button.

z
The adjusted time is established.
7) Press

to select [DAY OF THE
WEEK].
8) Press
󱽃󱽄
to switch [DAY OF THE
WEEK].

z
The setting will change as follows each time
you press the button.
[SUNDAY] [MONDAY] [TUESDAY]
[WEDNESDAY]
[SATURDAY] [FRIDAY] [THURSDAY]
Note
z
The [LAMP RELAY] function is enabled when
[SINGLE], [DUAL], [TRIPLE], or [QUAD] is selected
in [LAMP SELECT].
z
When [SINGLE] or [DUAL] is selected in [LAMP
SELECT], the lamp switches to the specied time.
When [TRIPLE] is selected in [LAMP SELECT], the
lamp switches a total of three times every two hours
from the specied time, and thereafter maintains
the previous status until the specied time.
When [QUAD] is selected in [LAMP SELECT],
three turn on at the specied time and the three
lamps switch every two hours for a total of four
