Panasonic PT-DZ21KU

Technical information
170 - ENGLISH
Appendix
■
Control command
The following table lists the commands that can be used to control the projector using a computer.

z
Projector control command
Command Details Remarks (parameters)
PON Power on
To check if the power is on, use the “Power query” command.
POF Power standby
QPW Power query 000 = Standby 001 = Power on
IIS
Switching the input
signal
VID=VIDEO RG1 = RGB1 RG2 = RGB2 DVI=DVI-D HD1 = HDMI
SD1 = SDI 1 (only for PT-DZ21KU, PT-DS20KU)
SD2 = SDI 2 (only for PT-DZ21KU, PT-DS20KU)
QSL
Query for active
lamp selection
0 = Quad
4 = Lamp 1/2/3
8 = Triple
*1
12 = Lamp 4
1 = Lamp 1/4
5 = Lamp 1/2/4
9 = Lamp 1
13 = Single
*1
2 = Lamp 2/3
6 = Lamp 1/3/4
10 = Lamp 2
3 = Dual
*1
7 = Lamp 2/3/4
11 = Lamp 3
LPM Lamp mode
0 = Quad
4 = Lamp 1/2/3
8 = Triple
*1
12 = Lamp 4
1 = Lamp 1/4
5 = Lamp 1/2/4
9 = Lamp 1
13 = Single
*1
2 = Lamp 2/3
6 = Lamp 1/3/4
10 = Lamp 2
3 = Dual
*1
7 = Lamp 2/3/4
11 = Lamp 3
Q$L
Lamp cumulative
operating time query
1 = Lamp 1 2 = Lamp 2 3 = Lamp 3 4 = Lamp 4
Response is 0000 to 2000
OSH Shutter 0 = End 1 = Execute
QSH Shutter status query 0 = End 1 = Execute
VSE Aspect switching
0 = Standard/ VID auto 1=4:3 2=16:9 5 = THROUGH
6 = HV FIT 9 = H FIT 10 = V FIT
QSE Aspect setting query
0 = Standard/ VID auto 1=4:3 2=16:9 5 = THROUGH
6 = HV FIT 9 = H FIT 10 = V FIT
OPP P IN P execute 0 = Off 1 = User 1 2 = User 2 3 = User 3
QPP P IN P setting query 0 = Off 1 = User 1 2 = User 2 3 = User 3
OCS
Sub memory
switching
01 to 96 = Sub memory number
QSB
Sub memory status
query
01 to 96 = Sub memory number
*1: Used from the lamp with the shortest cumulative operating time.

z
Projector control command (with sub command)
Command Sub command Details Notes
VXX RYCI1 RGB1 input setting +00000=RGB/YP
B
P
R
, +00001 = Y/C

z
Lens control command
Command Sub command Details Notes
VXX LNSI2 Lens H shift
+00000 = Fine tuning 1+, +00001 = Fine tuning 1–,
+00100 = Fine tuning 2+, +00101 = Fine tuning 2–,
+00200 = Coarse adjustment+, +00201 = Coarse
adjustment–
VXX LNSI3 Lens V shift
VXX LNSI4 Lens focus
VXX LNSI5 Lens zoom
