Technical information
162 - ENGLISH
Appendix
■
PJLink security authentication
The password used for PJLink is the same as that of the password set for Web control.
When using the projector without security authentication, do not set a password for Web control.
z
For specications regarding PJLink, refer to the Japan Business Machine and Information System
Industries Association website.
URL http://pjlink.jbmia.or.jp/english/
Using Art-Net function
The network function of the projector supports the Art-Net function. Using the Art-Net protocol, you can control the
projector settings with the DMX controller and application software.
■
Channel denition
The following table lists the channel denitions used for controlling the projector with the Art-Net function.
Channel Control details Performance Parameter Remark
1 Shutter control
SHUTTER:OPEN 0-63
No operation 64-191
SHUTTER:CLOSE 192-255
2 Input selection
No operation 0-7
RGB1 8-15
RGB2 16-23
VIDEO 24-31
DVI-D 32-39
HDMI 40-47
SDI 1 48-55
(Only for
PT-DZ21KU/PT-DS20KU)
SDI 2 56-63
No operation 64-127
Execute P IN P, USER1 128-135
Execute P IN P, USER2 136-143
Execute P IN P, USER3 144-151
No operation 152-255
3 Lens function select
No operation 0-15
Lens H shift 16-31
Operate together with “Lens
adjustment” of the channel 4.
Lens V shift 32-47
Lens focus 48-63
Lens zoom 64-79
Move to the home position 80-95
Operate together with
“Command performance
execute” of the channel 4.
No operation 96-255
