Panasonic PT-RZ670

Chapter 6 Appendix — Technical information
166 - ENGLISH
PJLink security authentication
The password used for PJLink is the same as that of the password set for web control.
When using the projector without security authentication, do not set a password for web control.
f For specications related to PJLink, refer to the website of Japan Business Machine and Information System Industries Association.
URL http://pjlink.jbmia.or.jp/english/
Using Art-Net function
Since the network function of the projector supports the Art-Net function, you can control the projector settings with the DMX controller or
application software using the Art-Net protocol.
Channel denition
The following table lists the channel denitions used for controlling the projector with the Art-Net function.
Channel Control details Performance Parameter Default value Remark
1
Light volume
adjustment
100 % 0
0
Can be set in 256 steps
between 100 % and 0 %.
… …
0 % 255
2 Input selection
No operation 0-7
0 ―
RGB1 8-15
RGB2 16-23
DVI-D 24-31
HDMI 32-39
DIGITAL LINK 40-47
SDI (Only for PT-RZ670) 48-55
No operation 56-127
Execute P IN P, USER1 128-135
Execute P IN P, USER2 136-143
Execute P IN P, USER3 144-151
No operation 152-255
3 Lens position
No operation 0-31
0 ―Move to the home position 32-63
No operation 64-191
4 Lens H shift
Lens
adjustment
(
- ) High speed 0-31
128
―
(
- ) Low speed 32-63
5 Lens V shift
(
- ) Fine
adjustment
64-95
128
Adjustment stop 96-159
6 Lens focus
Lens
adjustment
(+) Fine
adjustment
160-191
128
(+) Low speed 192-223
7 Lens zoom (+) High speed 224-255 128
8 Power supply control
Standby 0-63
128 ―No operation 64-191
Power on 192-255
9 GEOMETRY
OFF 0-15
255
(Only for PT-RZ670)
To use PC-1, PC-2, and
PC-3, the optional Upgrade
Kit (Model No.: ET-UK20) is
required.
KEYSTONE 16-31
CURVED 32-47
PC-1 48-63
PC-2 64-79
PC-3 80-95
CORNER CORRECTION 96-111
No operation 112-255
10 CUSTOM MASKING
OFF 0-31
255
(Only for PT-RZ670)
To use this function, the
optional Upgrade Kit (Model
No.: ET-UK20) is required.
PC-1 32-63
PC-2 64-95
PC-3 96-127
No operation 128-255
