Panasonic PT-RZ670

Chapter 4 Settings — [POSITION] menu
ENGLISH - 79
[POSITION] menu
On the menu screen, select [POSITION] from the main menu, and select an item from the sub-
menu.
Refer to “Navigating through the menu” (x page 67) for the operation of the menu screen.
f After selecting the item, press asqw to adjust.
Note
f When the optional Digital Interface Box (Model No.: ET-YFB100G) is connected to the <DIGITAL LINK/LAN> terminal, adjust the shift,
aspect, and clock phase from the menu of ET-YFB100G at the beginning.
[SHIFT]
Move the image position vertically or horizontally if the image projected on the screen is still out of position even when the positions of the
projector and screen are correct.
1) Press as to select [SHIFT].
2) Press the <ENTER> button.
f The [SHIFT] screen is displayed.
3) Press asqw to adjust the position.
Orientation Operation Adjustment
Vertical (up and down)
adjustment
Press a.
The image position moves up.
Press s.
The image position moves down.
Horizontal (right and left)
adjustment
Press w.
The image position moves to the right.
Press q.
The image position moves to the left.
Note
f For the portrait setting, image position is moved horizontally when “Vertical (up and down) adjustment” is made. Image position is moved
vertically when “Horizontal (right and left) adjustment” is made.
[ASPECT]
You can switch the aspect ratio of the image.
The aspect ratio is switched within the screen range selected in [SCREEN SETTING]. Set [SCREEN SETTING] rst. (x page 92)
1) Press as to select [ASPECT].
