Panasonic SC-HM910 - Page 103

SC-HM910/SC-HM810
103
Ref. No. Part No. Part Name & Description Remarks Ref. No. Part No. Part Name & Description Remarks
R981 ERDS2TJ102T RESISTOR PANEL S908 EVQ21405R TACT SWITCH
R982 D0GB332JA002 RESISTOR MAIN S909 EVQ21405R TACT SWITCH
R982 ERDS2TJ102T RESISTOR PANEL S910 EVQ21405R TACT SWITCH
R983 ERJ3GEY0R00V RESISTOR MAIN S911 EVQ21405R TACT SWITCH
R983 ERJ3GEYJ102V RESISTOR ** S912 EVQ21405R TACT SWITCH
R983 ERDS2TJ103T RESISTOR * S913 EVQ21405R TACT SWITCH
R984 D0GB393JA002 RESISTOR MAIN S914 EVQ21405R TACT SWITCH
R984 ERDS2TJ183T RESISTOR ** S951 RSH1A018-3U TACT SWITCH
R984 ERDS2TJ472T RESISTOR PANEL * S952 RSH1A019-2U TACT SWITCH
R985 D0GB392JA002 RESISTOR S971 RSH1A018-3U TACT SWITCH
R986 D0GB393JA002 RESISTOR S972 RSH1A019-2U TACT SWITCH
R987 D0GB334JA002 RESISTOR S974 RSH1A019-2U TACT SWITCH
R988 ERJ3GEYJ102V RESISTOR S975 RSH1A019-2U TACT SWITCH
R989 ERJ3GEYJ104V RESISTOR
R990 D0GB152JA002 RESISTOR MAIN
R990 ERDS1FVJ390T RESISTOR PANEL
R991 ERJ3GEYJ221V RESISTOR T502 RTP1H3C001 BACK UP TRANSFORMER *
R992 D0GB272JA002 RESISTOR T701 RTP1H3C001 BACK UP TRANSFORMER **
R993 ERJ3GEYJ102V RESISTOR T501 RTPM1P3M023-V TRANSFORMER *
R994 ERJ3GEYJ472V RESISTOR T700 RTPM1P3M022-V TRANSFORMER **
R995 D0GB272JA002 RESISTOR
R996 D0GB101JA002 RESISTOR
R997 ERJ3GEYJ153V RESISTOR * VR900 RRV16B24104G VARIABLE RESISTOR
R998 ERJ3GEYJ222V RESISTOR VR930 RRVM06A1C24 VARIABLE RESISTOR
R999 ERJ3GEYJ153V RESISTOR *
W1 REE0854 WIRE **
W1 REEX0060 WIRE *
RL502 RSY0056M-C RELAY * W1 REVM0102 WIRE **
RLY700 RSY0056M-C RELAY ** W1002 RWJ0102050KR-1 WIRE
W2 REEX0060 WIRE **
W2 REE0854 WIRE *
W500 REXX0202-1 WIRE
S602 EVQ21405R TACT SWITCH W500 REXX0235 WIRE
S603 EVQ21405R TACT SWITCH W601 REXX0298 WIRE
S604 EVQ21405R TACT SWITCH W605 RWJ1103130XQ WIRE
S605 EVQ11V07B TACT SWITCH W700 REXX0202-1 WIRE **
S606 EVQ11V07B TACT SWITCH W920 REXM0027 WIRE
S607 EVQ11V07B TACT SWITCH W921 REXM0026 WIRE
S608 EVQ11V07B TACT SWITCH W922 REXM0028 WIRE
S609 EVQ11V07B TACT SWITCH W923 RWJ1112100RR WIRE
S610 EVQ11V07B TACT SWITCH
S612 EVQ21405R TACT SWITCH
S613 EVQ21405R TACT SWITCH X102 RLFDFT22DD OSCILLATOR
S614 EVQ11V07B TACT SWITCH X103 RSXC7M20S05T OSCILLATOR
S615 EVQ11V07B TACT SWITCH X301 H0A327200073 OSCILLATOR
S616 EVQ11V07B TACT SWITCH X303 H2A100500006 OSCILLATOR
S617 EVQ11V07B TACT SWITCH X600 RSXZ4M19D01T OSCILLATOR
S618 EVQ21405R TACT SWITCH
S619 EVQ21405R TACT SWITCH
S620 EVQ21405R TACT SWITCH Z101 RLA2Z007-T COIL
S621 EVQ21405R TACT SWITCH Z102 G2BAE0000003 AM IF BLOCK
S900 EVQ21405R TACT SWITCH Z501 ERZV10V511CS ZNR *
S901 EVQ21405R TACT SWITCH Z701 ERZV10V511CS ZNR **
S902 EVQ21405R TACT SWITCH Z940 GP1UM272RK REMOTE SENSOR
S903 EVQ21405R TACT SWITCH Z971 RGSD12A1445T RADA RESISTOR
S904 EVQ21405R TACT SWITCH
S905 EVQ21405R TACT SWITCH
S906 EVQ21405R TACT SWITCH F1 XBA1C40NBAL FUSIBLE *
S907 EVQ21405R TACT SWITCH F1 XBA1C40NBAL FUSIBLE **
FUSES
OSCILLATORS
COMPONENT COMBINATION
SWITCHES
TRANSFORMERS
V
ARIABLE RESISTORS
RELAY
WIRES
