Panasonic SC-HM910 - Deck Mechanism Parts List

SC-HM910/SC-HM810
83
20.1.2.Deck Mechanism Parts List
Ref. No. Part No. Part Name & Description Remarks
101 RED0064-1
R/P HEAD BLOCK UNIT
102 RED0063-1
R/B HEAD BLOCK UNIT
103 RDG0300
REEL BASE GEAR
104 RDG0301
WINDING RELAY GEAR
105 RDK0026-4
MAIN GEAR
106 RDR0029-4
RELAY PULLEY
107 RDV0033-4
WINDING BELT
108 RDV0034-2
CAPSTAN BELT "A"
109 RDV0057-1
MAIN BELT B
110 RMB0312
TRIGGER LEVER SPRING
111 RMB0400-J
REEL SPRING
112 RMB0403
HEAD PANEL SPRING
113 RMB0404
BRAKE ROD SPRING
114 RMB0406-5
FR LEVER SP
115 RMB0408-J
THRUST SPRING
116 RML0370-4
TRIGGER LEVER
117 RML0371
FR LEVER
118 RML0372-2
WINDING LEVER
119 RML0374-2
EJECT LEVER
120 RMM0131-1
BRAKE ROD SPRING
121 RMM0133-1
EJECT ROD
122 RMQ0519
REEL HUB
123 RMS0398-1
MOVING CORE
124 RSJ0003
PLUNGER
125 RMC0061
PACK SPRING
126 RXF0049
FLYWHEEL "F" ASSY
127 RXF0050
FLYWHEEL "R" ASSY
128 RXG0040
FF RELAY GEAR ASSY
129 RMK0283A-2
SUB CHASSIS
130 RXL0124
PINCH ROLLER "F" ASSY
130-1 RMB0401
PINCH ARM SPRING "F"
131 RXL0125
PINCH ROLLER "R" ASSY
131-1 RMB0402
PINCH ARM SPRING "R"
132 RXL0126
WINDING ARM ASSY
133 RXQ0412-1
HEAD PANEL ASSY
133-1 RMB0405-1
FR ROD SPRING
133-2 RMM0132-1
FR ROD
134 REM0088
CAP MOTOR ASSY
135 RHD26022
MOTOR SCREW
136 XTW2+5L-A
HEAD BLOCK UNIT SCREW
137 XTW26+10S-A
SUB-CHASSIS SCREW
138 XYC2+JF17-A
PCB EARTH SCREW
139 RMK0282
CHASSIS ASSY
CASSETTE DEC
K
