SC-HM910/SC-HM810
30
7.12. Measure for tape trouble
• Follow the (Step 1) - (Step 2) of item 7.1
Step 1 If a cassette tape cannot be removed from the deck
since the tape is caught by the capstan or pich roller
during playback or recording, rotate the flywheel F in
the direction of the arrow to remove the tape.
Step 2 Force the lever upward and open the cassette lid ass’y.
Take the cassette tape off.
Cassette
lid
ass’y
To Next Page
