Panasonic SC-HM910 - Cabinet Parts List

SC-HM910/SC-HM810
89
20.3.2.Cabinet Parts List
42 RSC0027-3 TUNER PACK
1 REEM0085 WIRE 17 PIN 43 RMNX0073 PCB SUPPORT
2 REEM0088 WIRE 10 PIN 44 RXXM0019 HEAT SINK UNIT
3 REEM0086 WIRE 30 PIN 45 RMKX0063 CD CHASSIS
4 RGWX0042-4S1 MIC-KNOB 46 RD-DAC024-PX CD MECHANISM
5 RYPM0123 PANEL FRONTAL HM910 47 RMNX0023-2 SUB TRANS HOLDER
6 RKF0462-K4 CASS HOLDER (L) 48 REM0072-4 FAN (ONLY HM910)
7 RKF0463-K4 CASS HOLDER (R) RGRM0008-B REAR PANEL HM910
8 RUS757ZAA CASSETTE HALF SPRING RGRX0014A-G REAR PANEL HM810
9 RMB0446 CASS OPEN SPRING 50 RYKM0027 TOP CABINET
10 RYQM0073 CASS. LID (L) 51 XTB3+10J-A SCREW
11 RYQM0074 CASS. LID (R ) 52 XTW3+15T-A SCREW
RKWX0182-H1 CASS. WINDOW (L) HM910 53 XTBS26+10J-A SCREW
RKWX0182-A1 CASS. WINDOW (L) HM810 54 XTW3+12T-A SCREW
RKWX0181-H1 CASS. WINDOW (R) HM910 55 XTB3+10JFZ-A SCREW
RKWX0181-A1 CASS. WINDOW (R) HM810 56 XTBS3+8JFZ1-A SCREW
14 RYRM0055 CD MANAGER BUTTON 57 XTB3+20J-A SCREW
15 RGUX0452-Q1 CD SELECTOR BUTTON 58 RHD30002-H SCREW
16 RYRM0058 CD EJECT BUTTON
17 RYRM0057 SUPER 3D AI
18 RYRM0061 SUPER SOUND EQ
19 RYQX0037-HM JOG JOY UNIT
20 RYRM0059 FUNCTION BUTTON
21 RYRM0060 DECK/MAIN UNIT
22 RGPX0072-Q REMOTE SENSOR
23 RDLX0002-Q POWER LENS
24 RYRM0054 POWER BUTTON
RGKX0124-H CD STR ORNAMENT HM910
RGKX0124-A CD STR ORNAMENT HM810
26 RYQM0068A-1 VOLUME KNOB
27 RKWM0030 FL FILTER
28 RKWX0180-Q FL WINDOW
RYQM0097 CENTER ORNAMENT HM910
RYQM0106 CENTER ORNAMENT HM810
30 RYQM0080 CD TRAY LID
RYQM0093 CD TRAY ORNAMENT HM910
RYQM0107 CD TRAY ORNAMENT HM810
RYQM0096 TOP ORNAMENT HM910
RYQM0095 TOP ORNAMENT HM810
33 RGB0036-A1 EMBLEMA
34 RAA3412-1P AUTOREVERSE DECK
35 XTWS3+10Q-A SCREW
36 RYRM0056 KARAOKE BUTTON
37 RYRM0062 BOTTOM EFFECTS
38 RMKX0035-1 BOTTOM CHASSIS
39 MDS013 POWER PCB SUPPORT
40 RMRX0030-1 HEAT SINK SUPPORT
41 MHPSJ5012-1 LEG RUBBER
CASSETTE DECK
12
13
25
29
31
32
49
