SC-HM910/SC-HM810
90
20.4. Electrical Parts List
* ONLY SC-HM810 ** ONLY SC-HM910
Ref. No. Part No. Part Name & Description Marks Ref. No. Part No. Part Name & Description Marks
C1020 ECJ1VB1H471K CAPACITOR
C1021 ECJ1VB1H471K CAPACITOR
RAIM033104P DECK C1022 F1H1H102A761 CAPACITOR
RAIM038100A TRANSFORMER C1023 F1H1H102A761 CAPACITOR
RAIM038101A POWER C1026 ECEA0JKA470B CAPACITOR
RAIM038102A MAIN C1027 F1H1H102A761 CAPACITOR
RAIM038103A PANEL C103 ECJ1VB1E103K CAPACITOR
RAIM03815A TUNER PACK C1030 ECEA1AKA101B CAPACITOR
C1031 ECEA1AKA101B CAPACITOR
C1032 F1C1C183A001 CAPACITOR
C1033 F1C1C183A001 CAPACITOR
RJBX0313A-2 DECK C1034 ECEA1HKA3R3B CAPACITOR
RJBM0027A-1 TRANSFORMER C1035 ECEA1HKA3R3B CAPACITOR
RJBM0025A-2 POWER C1036 ECUV1C333KBV CAPACITOR
RJBM0039A MAIN C1037 ECEA1HKA3R3B CAPACITOR
RJBM0038A PANEL C1038 ECJ1VB1H221K CAPACITOR
RJBX0066B-1 TUNER PACK C1039 ECJ1VB1H221K CAPACITOR
C104 F1H1H102A761 CAPACITOR
C1040 ECEA1CKA100B CAPACITOR
C1041 ECEA1CKA100B CAPACITOR
RAIM033104P DECK C1042 ECEA1CKA220B CAPACITOR
RAIM039100A TRANSFORMER C1043 ECEA1HKA4R7B CAPACITOR
RAIM039101A POWER C1044 ECEA1AKA330B CAPACITOR
RAIM039102A MAIN C1045 ECEA1AKA220B CAPACITOR
RAIM039103A PANEL C1046 ECEA1AKA221Q CAPACITOR
RAIM03815A TUNER PACK C1047 ECEA1HKA010B CAPACITOR
C1048 ECEA1HKA010B CAPACITOR
C1049 F1H1H102A761 CAPACITOR
C1050 F1H1H102A761 CAPACITOR
RJBX0313A-2 DECK C1051 ECEA1HKA010B CAPACITOR
RJBM0023A-1 TRANSFORMER C1052 ECEA1HKA010B CAPACITOR
RJBM0021A-2 POWER C1053 ECA1CM221B CAPACITOR
RJBM0039A MAIN C1054 ECEA1HKA3R3B CAPACITOR
RJBM0038A PANEL C1055 ECEA1HKA0R1B CAPACITOR
RJBX0066B-1 TUNER PACK C1056 ECEA1CKA100B CAPACITOR
C1057 F1H1H102A761 CAPACITOR
C1058 F1H1H102A761 CAPACITOR
C106 ECJ1VB1E103K CAPACITOR
C1 ECBT1H5R6KC5 CAPACITOR C1064 ECEA1HKA3R3B CAPACITOR
C10 ECBT1H180JC5 CAPACITOR C107 F1H1E473A062 CAPACITOR
C1001 F1H1H103A753 CAPACITOR C108 F1H1H8R0A787 CAPACITOR
C1002 ECEA1HKN2R2B CAPACITOR C109 F1H1H102A761 CAPACITOR
C1003 ECUV1H152KBV CAPACITOR C11 RCBS1H102KBY CAPACITOR
C1006 ECEA1HKA010B CAPACITOR C110 ECJ1VB1E103K CAPACITOR
C1007 F0A2A472A015 CAPACITOR C111 ECEA1HKA4R7B CAPACITOR
C1008 ECEA1HKA010B CAPACITOR C112 ECJ1VB1E103K CAPACITOR
C1009 ECEA1AKA470B CAPACITOR C113 F1H1H102A761 CAPACITOR
C101 ECJ1VB1E103K CAPACITOR C114 ECEA1HKA3R3B CAPACITOR
C1010 ECA1EM101B CAPACITOR C115 ECEA1HKA4R7B CAPACITOR
C1011 ECQV1H473JZ3 CAPACITOR C116 ECUV1C333KBV CAPACITOR
C1012 F1H1H102A761 CAPACITOR C117 ECJ1VB1E103K CAPACITOR
C1013 F1H1H102A761 CAPACITOR C118 ECJ1VB1E103K CAPACITOR
C1014 F1H1H102A761 CAPACITOR C119 F0A2A681A010 CAPACITOR
C1015 F1H1H102A761 CAPACITOR C120 ECEA1CKA100B CAPACITOR
C1016 ECJ1VB1H222K CAPACITOR C121 ECEA1HKAR47B CAPACITOR
C1017 ECJ1VB1H222K CAPACITOR C122 ECEA1HKA010B CAPACITOR
C1018 ECJ1VB1H103K CAPACITOR C123 ECEA1HKA010B CAPACITOR
C1019 F1H1H102A761 CAPACITOR C124 ECJ1VC1H101K CAPACITOR
C102 ECEA1CKA100B CAPACITOR C125 ECEA1CKA220B CAPACITOR
P.C.B. WITH COMPONENTS SC-HM810
P.C.B. WITHOUT COMPONENTS SC-HM810
P.C.B. WITH COMPONENTS SC-HM910
P.C.B. WITHOUT COMPONENTS SC-HM910
CAPACITORS
