Panasonic SC-HM910 - Error Code Descriptions; Cassette Mechanism Errors; CD Changer Errors; Power Supply Errors

SC-HM910/SC-HM810
32
9 Description of Error Code
9.1. Error detection for Cassette Mechanism block
9.2. Error detection for CD Changer block
9.3. Power Supply related error detection
No. Error
Error
Dis
p
la
y
Problem condition
1 MODE SW H01 Faulty operation of cassette mechanism.
detection error Faulty contact or short-circuit of mechanism mode switch (S951, S971).
2 REC INH SW H02 Recording not possible.
detection error Faulty contact or short-circuit of REC INH switch (S975).
3 HALF SW H03 Playback cannot perform.
detection error Faulty contact or short-circuit of HALF switch (S952, S972).
4 Reel Pulse F01 The tape advances slightly and then stops.
detection error Faulty reel pulse, faulty hole detect IC (IC951, IC971).
5 TPS abnormal F02 Cassette deck will not perform TPS function.
Faulty playback EQ/recording amplifier IC (IC1001).
No. Error
Error
Dis
p
la
y
Problem condition
1 REST SW detection error F15 CD does not funcion
This error occurs when the Optical Pick up REST SW (S701) is not
detected within the specified time (about 8 seconds)
2 CD tray opens automatically F16 CLAMP switch (SW4) ng (Check & Replace)
3 Does not starup when (PLAY) F17 BOTTOM switch (SW5) NG (Check & Replace)
Button is pressed
4 Transmission error between CD F26 CD does not funcion
sevo LSI and micon This error occurs when the POWER is ON for the CD block and an error
is detected after the transmisission has started.
5 Starup fails even when you F27 Tray 1 detect switch or Tray 2 detect swith NG (Check & Replace)
insert CD or the selected disc tray
does not open
6 Cannot insert CD F28 Tray 1 detect switch NG (Check & Replace)
7 Cannot eject CD F29 Check if disc is stuck. Tray 2 detect switch NG (Confirm & Replace)
8 The CD tray closes H15 CD disc tray detect switch NG (SW3) (Check & Replace)
No. Error
Error
Dis
p
la
y
Problem condition
1 POWER AMP F61 When POWER is switched on, power become off automatically.
output abnormal During normal operation, if DC DET become L, PCNT shall become
L and the error display on the left shall be displayed. (IC501)
