Parker AC10 series User Manual

Modbus Communication 12-5
AC10 Inverter
Reading
parameter
address
Function Remarks
100A Read integer power value The integer power value is read by PC.
100B DI terminal status DI1~DI6—bit0~bit5
100C Terminal output status bit0-OUT1 bit0-OUT2 bit2-fault relay
100D AI1 0~4095 read input analog digital value
100E AI2 0~4095 read input analog digital value
1010 Reserved
1011 0 - 10000 0 - 100.00% the percent of input pulse
1012 0 - 10000 0 – 100.00% the percent of output pulse
1013 Present-stage speed value
0000 : no function
0001 : stage speed 1
0010 : stage speed 2
0011 : stage speed 3
0100 : stage speed 4
0101 : stage speed 5
0110 : stage speed 6
0111 : stage speed 7
1000 : stage speed 8
1001 : stage speed 9
1010 : stage speed 10
1011 : stage speed 11
1100 : stage speed 12
1101 : stage speed 13
1110 : stage speed 14
1111 : stage speed 15
Monitoring in which stage speed inverter is.
1014 External counting value Monitoring external counting value
1015
AO1 （0~100.00）
Monitoring analog output percent
1017 Current speed Monitoring current speed.
1018 Read accurate power value Correct the power to 1 decimal place.
