Parker AC10 series User Manual

13-5 The Default Applications
AC10 Inverter
Two Run inputs and two Set-point inputs are provided. The Auto/Manual switch selects which
pair of inputs is active. The Application is sometimes referred to as Local/Remote.
Application 2 : Auto/Manual Control
Parameters Setting:
F228 = 2
F106 = 2
F203 = 1
F204 = 2
F207 = 2
F316 = 56
F317 = 57
F318 = 55
F319 = 58
F320 = 8
F431 = 0
Coast stop
1
2
3
5
6
4
7
8
9
10
11
12
13
14
15
16
17
18
TA
TB
TC
1DO
24V
CM
DI1
DI2
DI3
DI4
DI5
10V
1AI
2AI
GND
1AO
A +
B -
REF
Direction
Auto
/
manual
select
Manual run
Auto run
Auto
setpoint
not used
not used
Analog output
F 431=0 ,
running
frequency is output.
GND
Auto setpointAI 2
input
4-20 mA
Manual setpoint
AI1 input 0-10V
10V
Coast stop
Direction
Auto / manual select
Manual run
Auto run
CM
24V
not used
Relay output
The function is valid,
inverter runs reverse.
The function is valid,
manual run is selected.
F 300=1 ,
inverter outputs
fault signal.
TC-Hydraulik - Rsdorfer Str. 8 - 25746 Heide - Lars Lornsen - T: +49 481 909 - 34 - l.lornsen@tc-hydraulik.de - www.tc-hydraulik.de

Parker AC10 series Specifications

General

Overload Capacity	150% for 60 seconds
Analog Inputs	2
Analog Outputs	1
Communication Options	Modbus RTU
Protection Rating	IP20
Input Voltage	200-240VAC, 380-480VAC, 500-575VAC, 600VAC, 690VAC
Digital Outputs	2
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Braking	Built-in dynamic braking
