Parameter Reference 15-7
AC10 Inverter
Function
Code
Function
Definition
Setting Range Mfr’s Value
Change
F316 DI1 terminal function setting 0: no function;
1: running terminal;
2: stop terminal;
3: multi-stage speed terminal 1;
4: multi-stage speed terminal 2;
5: multi-stage speed terminal 3;
6: multi-stage speed terminal 4;
7: reset terminal;
8: free stop terminal;
9: external coast stop terminal;
10: acceleration/deceleration
forbidden terminal;
11: forward run jogging;
12: reverse run jogging;
13: UP frequency increasing
terminal;
14: DOWN frequency decreasing
terminal;
15: “FWD” terminal;
16: “REV” terminal;
17: three-line type input “X” terminal;
18: accel/decel time switchover 1;
19: Reserved;
20: Reserved;
21: frequency source switchover
terminal;
32: Fire pressure switchover
33: Emergency fire control
34: Accel / decel switchover 2
37: Common-open PTC heat
protection
38: Common-close PTC heat
protection
48: High-frequency switchover
52: Jogging (no direction)
53: Watchdog
54: Frequency reset
55: switchover between manual
running and auto running
56: Manual running
57: Auto running
58: Direction
11
F317 DI2 terminal function setting 9
F318 DI3 terminal function setting 15
F319 DI4 terminal function setting 16
F320
F321
DI5 terminal function setting
DI6 terminal function setting
7
8
F324 Free stop terminal logic
0: positive logic (valid for low level);
1: negative logic (valid for high
level)
0
F325 External coast stop terminal logic 0
F326 Watchdog time 0.0~3000.0 10.0
F327 Stop mode
0: Free stop 1: Deceleration to
stop
0
F328 Terminal filter times
1100
10
