15-6 Parameter Reference
AC10 Inverter
Multifunctional Input and Output Terminals: F300-F330
Function
Code
Function
Definition
Setting Range Mfr’s Value
Change
F300 Relay token output 0: no function;
1: inverter fault protection;
2: over latent frequency 1;
3: over latent frequency 2;
4: free stop;
5: in running status 1;
6: DC braking;
7: accel/decel time switchover;
8-9: Reserved;
10: inverter overload pre-alarm;
11: motor overload pre-alarm;
12: stalling;
13: Inverter is ready to run
14: in running status 2;
15: frequency arrival output;
16: overheat pre-alarm;
17: over latent current output
18: Analog line disconnection
protection
19: Reserved;
20: Zero current detecting output
21: DO1 controlled by PC/PLC
22: Reserved;
23: TA, TC fault relay output
controlled by PC/PLC
24: Watchdog
25-39: Reserved;
40: High-frequency performance
switchover
1
F301 DO1 token output 14
5
F303-
F306
Reserved
F307 Characteristic frequency 1 F112F111 10.00
F308 Characteristic frequency 2
F112F111
50.00
F309 Characteristic frequency width (%)
0100
50
F310 Characteristic current (A)
01000
Rated
current
F311 Characteristic current width (%)
0100
10
F312 Frequency arrival threshold (Hz)
0.005.00
0.00
F313-
F315
Reserved
