Parker AC10 series User Manual

Parameter Reference 15-9
AC10 Inverter
Function
Code
Function
Definition
Setting Range
Mfr’s Value
Change
F423
AO1 output range
0
：0～5V；
1
：0～10V or 0-20mA
2: 4
-20mA
1
√
F424
AO1 lowest
corresponding frequency
0.0
～F425
0.05Hz
√
F425
AO1 highest corresponding frequency
F424
～F111
50.00Hz
√
F426
AO1 output compensation
0
～120
100
√
F427
-
F430
Reserved
F431
AO1 analog output signal selecting
0: Running frequency;
1: Output current;
2: Output voltage;
3: Analog AI1;
4: Analog AI2;
6: Output torque;
7: Given by PC/PLC;
8: Target frequency
0
√
F433
Corresponding current for full range of external
voltmeter
0.01
～5.00 times of rated current
2
╳
F434
Corresponding
current for full range of external
ammeter
2
╳
F435
-
F436
Reserved
F437
Analog filter width
1
～100
10
*
F438
-
F459
Reserved
F460
AI1channel input mode
0: straight line mode
1: folding line mode
0
╳
F461
AI2 channel input mode
0: straight line mode
1: folding line mode
0
╳
F462
AI1 insertion point A1 voltage value
F400
～F464
2.00V
╳
F463
AI1
insertion point A1 setting value
F401
～F465
1.20
╳
F464
AI1
insertion point A2 voltage value
F462
～F466
5.00V
╳
F465
AI1
insertion point A2 setting value
F463
～F467
1.50
╳
F466
AI1
insertion point A3 voltage value
F464
～F402
8.00V
╳
F467
AI1
insertion point A3 setting value
F465
～F403
1.80
╳
F468
AI2
insertion point B1 voltage value
F406
～F470
2.00V
╳
F469
AI2
insertion point B1 setting value
F407
～F471
1.20
╳
F470
AI2
insertion point B2 voltage value
F468
～F472
5.00V
╳
F471
AI2
insertion point B2 setting value
F469
～F473
1.50
╳
F472
AI2
insertion point B3 voltage value
F470
～F412
8.00V
╳
F473
AI2
insertion point B3 setting value
F471
～F413
1.80
╳
