Parker AC10 series User Manual

AC10
series
IP66 0 – 15kW
Product Manual
HA502703U001 Issue 1
2014 Parker Hannifin Manufacturing Ltd.
All rights strictly reserved. No part of this document may be stored in a retrieval system, or transmitted in any form
or by any means to persons not employed by a Parker SSD Drives company without written permission from
Parker SSD Drives, a division of Parker Hannifin Ltd . Although every effort has been taken to ensure the accuracy
of this document it may be necessary, without notice, to make amendments or correct omissions. Parker SSD
Drives cannot accept responsibility for damage, injury, or expenses resulting therefrom.
WARRANTY
The general terms and conditions of sale of goods and/or services of Parker Hannifin Europe Sarl, Luxembourg,
Switzerland Branch, Etoy, apply to this product unless otherwise agreed. The terms and conditions are available
on our website www.parker.com/terms andconditions/switzerland
TC-Hydraulik - Rsdorfer Str. 8 - 25746 Heide - Lars Lornsen - T: +49 481 909 - 34 - l.lornsen@tc-hydraulik.de - www.tc-hydraulik.de

Parker AC10 series Specifications

General

Overload Capacity	150% for 60 seconds
Analog Inputs	2
Analog Outputs	1
Communication Options	Modbus RTU
Protection Rating	IP20
Input Voltage	200-240VAC, 380-480VAC, 500-575VAC, 600VAC, 690VAC
Digital Outputs	2
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Operating Temperature	-10°C to +50°C
Humidity	5% to 95% (non-condensing)
Dimensions	Varies by model
Weight	Varies by model
Braking	Built-in dynamic braking
