Parker COMPAX-M /-S (L) - Motor Output Throttle

Accessories and options
COMPAX-M / -S
EMC measures
192
COMPAX 25XXS: motor cable >10m
COMPAX 10XXSL: motor cable >50m
COMPAX 25XXS: motor cable
≤
≤≤
≤
10m
Type: NFI01/01 dimension diagr.: Type: NFI01/06 dimension diagram:
50.8±0.3
85.4
116
139
79.5
101
88.9±0.4
55.5
Ø 4
5.2 x 4
L
I
N
E
L
O
A
D
66 max.
91 max.
51 max.
75 ±0.3
5.3
L
N
FASTON
6.3 x 0.8
L'
N'
LINE
LOAD
27
12
32 max.
3.5
20
• Unscreened: <0.5m
♦
Screened: <5m
9.7.4.2 Motor output throttle
We supply motor output throttles for use with long motor lines (greater than 20m)
♦
Type: MDR01/01 16A / 2mH
♦
Type: MDR01/02 30A / 1.1mH
♦
Type: MDR01/03 >30A / 0.64mH
M
motor
PE
PE
U
V
W
Br+
Br-
+
+
-
-
U1
U2
V2
V1
W1
W2
motor output filterdevice
COMPAX 25XXS:
COMPAX 10XXSL
Length of
connection between
power filter and
unit:
Up to 16A
nominal motor
current:
Up to 30A
nominal motor
current:
Over 30A nominal
motor current:
Wiring of motor
output throttle
MDR01/01 MDR01/02 MDR01/03
A [mm] 150 180 205
B [mm] 67 76 107
D [mm] 113 136 157
E [mm] 50 57 83
F [mm] 6 6 7
H [mm] 195 195 260
I [mm] 95 110 150
Weight [kg] 4 6 17
A
B
I
F
D
E
H
U1 V1 W1 + - U2 V2 W2 + -
