Parker COMPAX-M /-S (L) - Mounting and Dimensions COMPAX 1000 SL

COMPAX 1000SL Unit characteristics
Mounting and dimensions COMPAX 1000SL
43
Unit
hardware
Connector
assignment / cable
Technical dataConfigurationPositioning and
control functions
Optimization
functions
InterfacesAccessories /
options
StatusParameterError list
7.7.3 Mounting and dimensions COMPAX 1000SL
Fieldbus InEncoder
Input / Output
Resolver
Fieldbus Out
Limit Switch
24 V DC
R
Dump
H2 H1
RS232
X6X5X13
X12
X17
X19
X2
X1 X4 X3
X14
X15
HEDA Out HEDA In
Input +-
L1 N PE
UV
W
PE + -
Motor
Brake
PE
230 V AC
85
180
206.5
145.5
197.5
16
5
55
174
+
-
COMPAX - SL
183
X7
Fastening: 3 M4 hex-socket head screws
Installation distance: 100mm (device distance:15mm)
