Parker EX Series User Manual

112 – Pvd3665_Gb_Ex_August 2022
Step 3 – Connection of the power cable :
1. Insert the cable in the cable gland Ref 2.
2. Strip the wires on 3 mm.
3. Put the wires U, V, W, Ground, TH+ and TH- and also BR+ and BR- in a case of a
motor with a brake in the terminal of the PCB Ref 4 and tighten each screws at the
torque value of 0,6N.m.
4. Make the shielding connection with the connection of the terminal on the screw ref
5 at the torque value of 2,5 N.m.
5. If the shielding connection is not necessary, cut the wire short the cable.
Step 4 – Fitting of the rear cover :
7. Slowly take up any slack in the cables and close the cover Ref 3.
8. Tighten the cable gland caps or conduits stop Ref 2.
9. Place the rear cover Ref 3 and take care to don’t hurt the toric seal placed on the
rear flange.
10. Tighten the 4 nuts Ref 1 at the torque value of :
Motor size
Torque (N.m)
EX6 M5 nuts
5,6
EX8 M6 nuts
8,5
11. Connect the outside ground with the screw Ref 7 and tighent it at the torque value
of :
Motor size
Torque (N.m)
EX6 M5 screw
5,6
EX8 M6 screw
8,5
