3.2.13. Voltage and current during the operating
The EX motors can carry ATEX, IECEx, CCC and UL certification and due to this certificate,
they are subjected to strict rules regarding their use. One of such rules is the us of a
servoamplifier that meets specific characteristics.
EX310 ATEX, IECEx, CCC :
Voltage of the associated speed
drive
24V direct
current
48V direct
current
230V single /
three phase
400V three
phase
Power supply direct current voltage (V)
24 ±10%
48 ±10%
310 ±10%
550 ±10%
Motor electrical frequency (Hz)
0 to 700
0 to 700
0 to 700
0 to 700
Steady peak current in a phase
(Â/Arms)
Max. 17/12
Max. 17/12
Max. 7.5/5.3
Max. 4/2.8
Maximum peak current in a phase
(Â/Arms)
Max. 34/24
Max. 34/24
Max. 15/10.6
Max. 8/5.6
Maximum steady motor power (W)
Max. 250
Max. 500
Max. 1900
Max. 1800
EX4 ATEX, IECEx, CCC :
EX6 ATEX, IECEx, CCC :
Voltage of the associated speed
drive
230V single / three phase
400V three phase
Power supply direct current voltage (V)
310 ±10%
550 ±10%
Motor electrical frequency (Hz)
0 to 500
0 to 500
Steady peak current in a phase
(Â/Arms)
Max. 25/17.7
Max. 16/11.3
Maximum peak current in a phase
(Â/Arms)
Max. 50/35.3
Max. 32/22.6
Maximum steady motor power (W)
Max. 6000
Max. 6000
EX8 ATEX, IECEx, CCC :
Voltage of the associated speed
drive
230V single / three phase
400V three phase
Power supply direct current voltage (V)
310 ±10%
550 ±10%
Motor electrical frequency (Hz)
0 to 500
0 to 500
Steady peak current in a phase
(Â/Arms)
Max 100/70.7
Max 50/35.3
Maximum peak current in a phase
(Â/Arms)
Max 200/141.4
Max 100/70.7
Maximum steady motor power (W)
Max 10 000
Max 10 000
Voltage of the associated speed
drive
24V direct
current
48V direct
current
230V single /
three phase
400V three
phase
Power supply direct current voltage (V)
24 ±10%
48 ±10%
310 ±10%
550 ±10%
Motor electrical frequency (Hz)
0 to 600
0 to 600
0 to 600
0 to 600
Steady peak current in a phase
(Â/Arms)
Max. 17/12
Max. 17/12
Max. 14/9.9
Max. 8/5.6
Maximum peak current in a phase
(Â/Arms)
Max. 34/24
Max. 34/24
Max. 28/19.8
Max. 16/11.3
Maximum steady motor power (W)
Max. 200
Max. 400
Max. 3400
Max. 3400
