Parker EX Series User Manual

117 – Pvd3665_Gb_Ex_August 2022
3.9.1. Cable option Max 80°C on the surface ATEX/IECEx
The servomotors EX are available on demand with cables withstanding a temperature of
80°C on the outside surface.
With this option the EX servomotors must be placed in an area with controlled temperature
following the informations written in the tables just below. An over temperature must cut off
the power of the motor.
Size EX4 :
EX4 certified for an ambient
temperature of -20 to +60°C
Ambient temperature for a Parker
standard cable using (Max 100°C)
-20 to +60°C
Ambient temperature for an using of
cables withstanding a max temperature
of 80°C.
-20 to +49°C
Size EX6 :
EX6 certified for an ambient
temperature of -20 to +40°C
EX6 certified for an ambient
temperature of -20 to +60°C
Ambient temperature for Parker
standard cable using (Max 100°C)
-20 to +40°C
-20 to +60°C
Ambient temperature for an using of
cables withstanding a max temperature
of 80°C.
-20 to +27°C
-20 to +45°C
Size EX8 :
EX8 certified for an ambient
temperature of -20 to +40°C
EX8 certified for an ambient
temperature of -20 to +60°C
Ambient temperature for Parker
standard cable using (Max 100°C)
-20 to +40°C
-20 to +60°C
Ambient temperature for an using of
cables withstanding a max temperature
of 80°C.
-20 to +32°C
-20 to +46°C
