116 Pvd3665_Gb_Ex_August 2022
3.9. Cables
You can connect EX motors to PARKER servo drives : AC30, AC890, COMPAX3, PSD or
SLVD.
You can use complete cable with part number on the tabs below.
The "xxx" in the part number must be replaced by the length in meter with a minimal length
of 3m.
Ex : for 20m cable, "xxx" = 020.
Special requirements for ATEX servomotors
For the ATEX installations in ambient temperature of 40°C or 60°C, you
have to use special cables C2 type auto-extinguish regarding the standard
EN 50265-2-1.
Warning : the cables used in the :
EX3 can reach a temperature of 80°C,
EX4 can reach a temperature of 91°C,
EX6 can reach a temperature of 95°C,
EX8 can reach a temperature of 94°C.
Warning : for a safe use, the EX3 servomotors has to be used with cable
which withstand a maximum temperature of 80°C.
Warning : for a safe use, the EX4/EX6/EX8 servomotors has to be used
with cable which withstand a maximum temperature of 100°C.
