114 Pvd3665_Gb_Ex_August 2022
3.8.13. Hiperface encoder singleturn EKS3618 bits code P
EX3, EX4, EX6 & EX8
Model
EKS36-2KF0B018A (Sick)
Type
Absolute single turn encoder
Parker part number
220174P0011
Electrical interface
Hiperface DSL
Position values per
revolution
18 bits
Revolutions count
1
Error limits for the digital
absolute value
± 120’’
Operating speed
12 000 rpm
Power Supply
Current consumption
(without load)
7VDC to 12VDC
Max 150 mA
Operating temperature
range
-20°C to +115 °C
Safety
SIL 2
3.8.14. Hiperface encoder multiturn EKM36 18 bits code Q
EX3, EX4, EX6 & EX8
Model
EKM36-2KF0B018A (Sick)
Type
Absolute multi turn encoder
Parker part number
220174P0012
Electrical interface
Hiperface DSL
Position values per
revolution
18 bits
Revolutions count
4 096
Error limits for the digital
absolute value
± 120’’
Operating speed
9000 rpm
Power Supply
Current consumption
(without load)
7VDC to 12VDC
Max 150 mA
Operating temperature
range
-20°C to +115 °C
Safety
SIL2
