Parsun F115 - Reverse Gear Shim; Forward Gear Shim

123
0.10, 0.12, 0.15, 0.18, 0.3, 0.4, 0.5 mm
Reverse gear shim
1. Check the F size marked on the housing of the underwater unit.
2. Formula: T1=58.7-20-4.5-33.3＋(F/100)=0.9+(F/100)
3. The shim can be reduced by 0~0.05mm compared with T1 (try to choose the most
similar size as possible)
4. Reverse gear shims (T1) that can be selected
0.10, 0.12, 0.15, 0.18, 0.3, 0.4, 0.5 mm
Forward gear shim
1. Check the R size marked on the housing of the underwater unit.
2. Formula: T2=39.8-33.2-6+(R/100)=0.6+(R/100)
3. The shim can be increased by 0~0.05mm compared with T2 (try to choose the most
similar size as possible).
4. Forward gear shims (T2) that can be selected:
0.10, 0.12, 0.15, 0.18, 0.3, 0.4, 0.5 mm
