10
Camshaf
t
Height Intake cam 41.011~41.111m
m
Valve opening height 4.3mm
Exhaust cam 41.27~41.37mm Fuel pump Displacement 1832L
Diameter of base circle 32.950～
33.050mm
Pressure 196kPa
Journal diameter 24.96~24.98mm Crankcase Crankshaft journal oil
clearance
0.014~0.050mm
Runout limit 0.03mm Thickness
of
crankshaft
main
journal
bearing
bush
A Blue 2.492~2.497mm
Oil
pump
Clearance between outer rotor and
shell
0.03~0.12mm B Green 2.497~2.503mm
Clearance between outer rotor and
inner rotor
0.12~0.16mm C Red 2.503~2.509mm
Clearance between rotor and cover 0.03~0.12mm
Va lv e Val ve
clearance
Intake valve 0.17~0.24mm
(Cold-state
)
Exhaust valve 0.31~0.38mm
Contact
width with
seat ring
Intake valve 1.1~1.5mm
Exhaust valve
Underwater unit
Item Data Item Data
Backlash
Drive gear
to forward
gear
Forward-rotating 0.15~0.87mm
Backlash
Forward
gear shim
0.10, 0.12, 0.15, 0.18, 0.30,
0.40, 0.50mm
Backward-rotating 0.13~0.87mm
Drive gear
to reverse
gear
Forward-rotating 0.74~1.56mm
Reverse
gear shim
0.10, 0.12, 0.15, 0.18, 0.30,
0.40, 0.50mm
Backward-rotating 0.75~1.56mm
Drive gear shim
0.10,0.12,0.15,
0.18, 0.30, 0.40, 0.50mm
