21
1. Oil dipstick 2. High mark 3. Low mark
2. If the oil level is above the high mark, discharge the engine oil; If the oil level is
below the low mark, add engine oil.
Note:
Run and then turn off the engine, and let it stand for several minutes; Check the oil level
with the oil dipstick again.
If the oil level is not within the specified range, add/discharge the oil to the specified
value.
Change engine oil
1. Remove the oil cap, oil drain bolt and bolt gasket; Discharge the oil.
2. Install new bolt gasket and install oil drain bolt.
3. Add engine oil through the oil port.
Engine oil level: 3.0 L (oil filter not changed)
3.2 L (oil filter changed)
Oil type: API: SG, SH, SJ, SL or SAE: 10W30, 10W40, 5W30
4. Install oil cap.
5. Check the oil level.
Note:
Before starting the outboard motor for the first time, make sure to fill the engine oil.
Otherwise, the engine will be severely damaged.
Spark plug
1. Remove the spark plug cap and then remove the spark plug.
2. Remove carbon deposits from the spark plug electrodes.
3. Check whether the electrodes are corroded, whether there are deposits and whether the
gaskets are damaged. If necessary, change the spark plug.
Spark plug model: NGK LKR6E
4. Check whether the electrode gap meets the specified value; If necessary, replace the
spark plug.
5. Install the spark plug and tighten it with the spark plug wrench according to the specified
torque.
Specified torque: 25 Nm
0.8-0.9mm
2
3
1
