Parsun F115 - Average Torque

13
Average torque
Mounting position Name Specification Quantity Torque
Underwa
ter unit
Drive bearing house Bolt M8x25
4
18 Nm
Cover nut - M102x2
1
103Nm
Pinion Nut
M16X1.5
90 Nm
Propeller nut Nut M18X1.5
1
55 Nm
Course tab Bolt
M10X1.25X45
1
42 Nm
About
water
Upper shock absorber Nut M14 2 74 Nm
Lower shock absorber Nut M14 2 74 Nm
Oil pan exhaust manifold Bolt
M10X1.25X45
6 42 Nm
Clamp bracket double
nipples
Nut
7/8-14UNF
2 22 Nm
Oil drain bolt Bolt M14X1.5 1 27 Nm
Coarse filter Bolt
M6X24
3 12 Nm
Steering bracket
Double-en
d bolt
M10X1.25X28
2
20 Nm
Nut
M10X1.25X28
2 40 Nm
Nut a Bolt b
Torque
8mm M5 5 Nm
10mm M6 8 Nm
12mm M8 18 Nm
14mm M10 36 Nm
17mm M12 43 Nm
