Parsun F115 - Electrical System

11
Electrical system
Item Data Item Data
Spark plug clearance 0.8~0.9mm
Trigger coil resistance* 290±20% Ω
Ignition coil
Secondary output
voltage
≥34KV
Primary resistance 2.2±0.22Ω
Output
voltage of
rectifier
regulator
1500 r/min
(Load)
14.5V
Secondary resistance 9.84±0.98KΩ
Peak output voltage of
magneto
1500 r/min (no-load) 53V
3500 r/min
(Load)
14.5V
3500 r/min (no-load) 115V
Magneto resistance
(green-green)
0.2Ω～0.3Ω
Peak voltage of trigger coil 1000 r/min ≥13V
* Data for reference only
