Parsun F115 - Seating Torque; Specified Torque

12
Seating torque
Specified torque
Mounting position Name Specification Quantity Torque
Engine
Fixed engine Bolt
M10X1.25X140
4 42 Nm
M10X1.25X45
2 42 Nm
M8X35
4 20 Nm
Upper shock absorber
Bolt
M14X195
2 74 Nm
Intake manifold bracket
Bolt
M8X35
2 24 Nm
Intake manifold
Bolt
M8X35
9 32 Nm
Spark plug
-
M12X1.25
4 25 Nm
Coil-on-plug
Bolt
M6X25
4 7 Nm
Driven pulley
Bolt
M10X1.25X35
2 60 Nm
Timing belt tensioner
assembly
Bolt
M10X1.25
1 39 Nm
Oil filter stud -
M20
1 49 Nm
Oil filter -
M20
1 18 Nm
Oil pressure sensor
-
M10
1 9 Nm
Container
body
1st
Bolt
M10X1.5X105
10
16 Nm
2nd
42 Nm
1st
Bolt
M8X55
10
14 Nm
2nd
28 Nm
Connecting
rod
1st
Bolt
M8X1X36
8
13 Nm
2nd
35 Nm
Cylinder
head
1st
Bolt
M10X1.5X110
10
15 Nm
2nd
30 Nm
3rd
80 Nm
Camshaft
cover A
1st
Bolt
M7X48
4
6 Nm
2nd
13 Nm
Camshaft
cover B
1st
Bolt
M7X37
16
6 Nm
2nd
13 Nm
Flywheel
1st
Bolt
M10X1X50
6
50 Nm
2nd
105 Nm
Exhaust pipe
A
1st
Bolt
M8X70
4
14 Nm
2nd
21 Nm
Exhaust pipe
B
1st
Bolt
M8X70
2
14 Nm
2nd
21 Nm
1st
Bolt
M8X100
2
14 Nm
2nd
21 Nm
Temperature sensor
Bolt
M14X1.5
1 23 Nm
Knock sensor
Bolt
M8
1 18 Nm
Limber board
Bolt
M6X25
9 12 Nm
Motor bracket
Bolt
M8X30 3
25 Nm
Start motor
Bolt
M8X45 3
33 Nm
