8
Specification
Outboard motor parameters
Item Data Item Data
Overall
dimensions
Full length 833 mm
Engine
Ignition
system
TCI
Overall width 517 mm
Spark plug LKR6E
Overall
height
L-type 1672 mm
X-type 1799 mm
Exhaust
system
Through the propeller hub
Stem
board
Height
L-type 510 mm
Lubrication
system
Purging-type oil mist lubrication
X-type 637 mm
Fuel
and oil
Fuel type Regular unleaded petrol
Weight
L-type 175kg Fuel grade PON86
X-type 179kg
Recommended
engine oil grade
API: SE, SF, SG,SH, SJ
SAE: 10W30, 10W40
Performance
Maximum output 85Kw@5600r/min Engine oil level
Total 3.8L
Do not change the
oil filter
3.0L
Change the oil
filter
3.2L
Full throttle
operating range
5300～6300 r/min
Recommended
gear oil
Hypoid gear oil SAE﹟90
Maximum fuel
consumption
38.9L/h@5600
r/min
Gear oil level
Forward-rotating 0.760L
Backward-rotating 0.715L
Idle (neutral
position)
800～900r/min
Bracket
Inclined rising
angle (degree)
70
Engine
Type
4-stroke, DOHC
L4, 16 valves
Number of
cylinders
4
Steering angle
(degree)
35+35
Displacement 1832cm³
Drive
Device
Gear F-N-R
Cylinder bore ×
stroke
81.0mm×88.9mm
Transmission
ratio
2.15
Compression
ratio
10:1 Gear type Spiral bevel gear
Minimum
compression
pressure
945kPa Clutch type Claw clutch
Lubricating oil
pressure
440kPa (at idle
speed)
Propeller shaft
type
Spline
Propeller
direction
Forward-rotating
Clockwise (rear
view)
Control system
Remote
control/steering
handle
Backward-rotating
Counterclockwise
(rear view)
Start-up system Electric starting
