5. Calculate the required thickness of the replaced valve tappet based on the formula.
Formula:
Required thickness of the valve tappet = a + measured valve clearance -specified valve
clearance
6. Load the selected valve tappet into the cylinder head, then mount the camshaft and
camshaft cap.
7. Mount the cylinder head cover with reference to steps 20-34 in the section "Check the
valve clearance".
Remove the engine
1. Open the top cover.
2. Remove the flywheel cover.
3. Disconnect the oil line, cooling water line and electrical wiring harness connector.
4. Remove the electrical parts and fuel system components with reference to the two
sections Electrical System and Fuel System.
5. Remove the housing of the water unit.
6. Remove the bolts connecting the engine and the water unit.
7. Lift the engine with a crane and remove the engine locating pin.
8. Remove the flywheel with special tools, remove the flywheel locating pin and keep it
well.
