When installing, apply oil to the sides of the piston and piston ring.
Installing crankshaft
1. Install crankshaft bearing bushes on the body separately.
2.Install the crankshaft to the engine body and install the oil seal.
Note:
Apply oil on the inside of the oil seal before installation.
3. Install the connecting rod bearing bush on the connecting rod.
4. Install the connecting rod cover to the connecting rod according to the connecting rod
pairing number and tighten the connecting rod bolts at the specified torque.
Seating torque: 13 Nm for the first time
35 Nm for the second time
5. Fit crankshaft locating plate A.
Note:
Face the notched side towards the crankshaft.
Assemble the engine base
1. Install the bearing bush on the engine base.
2. Install crankshaft locating plate B.
Note:
Face the notched side towards the crankshaft.
3. Coat sealant on the joint surface of the engine base, and install the locating pin and the
engine base.
Tighten the bolts twice in the order shown in the figure.
Seating torque:
Frist
tightening
M10×1.5
16 Nm
Second
tightening
42 Nm
Frist
tightening
M8
14 Nm
Second
tightening
28 Nm
Note:
Before installation, apply oil to the moving surface.
Apply oil to the bolts before installation.
4. Install oil filter bracket.
Note:
Use new rubber sealing rings.
5. Install oil filter with special tools and tighten it at specified torque.
Seating torque: 18 Nm
