PAX S300 User Manual

S300_V1.00.00 User Manual
NOTE: This document is CONFIDENTIAL and must be used exclusively for the operation of PAX programs. It may not be
duplicated, published, or disclosed without PAX prior written permission. 14
2.3 Key Definitions
Note
Below are Key Definitions of S300 POS terminal.
KEY
FUNCTION
0-9 Number Keys
Enter any numeric value. Or press for more than one time to enter
characters of alphabet.
CANCEL
Used to cancel an operation.
Access to the function menu for S300.
CLEAR
Erases character under the cursor when editing data.
ENTER
Accepts entered information. Executes the current function.
Access to the main application menu for S300.
2.4 Keypad Layout
Note
Below are examples of the keypad layout of the S300 POS terminal.

PAX S300 Specifications

General

Processor	32-bit ARM11
Security	PCI PTS 3.x approved
Card Readers	Magnetic Stripe, Contactless
Connectivity	RS232, USB, Ethernet
Memory	128MB Flash, 64MB SDRAM
