PAX S300 User Manual

S300_V1.00.00 User Manual
NOTE: This document is CONFIDENTIAL and must be used exclusively for the operation of PAX programs. It may not be
duplicated, published, or disclosed without PAX prior written permission. 168
5.7.3 Connect Timeout
Note
Use this feature to set the timeout for connection.
STEP
ACTION
DISPLAY
1.
From the Main Menu
press [5] to access the
Comm. Menu.
2.Operation Settings
5. Communication
3. Host Settings
Main Menu
1.Merchant Settings
4. System Settings
2.
Input the Password and
press [ENTER].
Please Enter Password:
3.
From the Communication
Options men, press [3] to
select the entry for
Connect Timeout.
4.Receive Timeout
2.Maximum Tries
Communication Options
1.Main Comm.
3.Connect Timeout
5.LAN Parameters 6.ECR Comm. Type

PAX S300 Specifications

General

Processor	32-bit ARM11
Security	PCI PTS 3.x approved
Card Readers	Magnetic Stripe, Contactless
Connectivity	RS232, USB, Ethernet
Memory	128MB Flash, 64MB SDRAM
