PAX S300 User Manual

S300_V1.00.00 User Manual
NOTE: This document is CONFIDENTIAL and must be used exclusively for the operation of PAX programs. It may not be
duplicated, published, or disclosed without PAX prior written permission. 151
4.
Select [1] or [2] to enter
the function:
[1] for starting Key
Injection process,
proceed to Step 5, then
skip to Step 8.
[2] for setting baud rate,
skip to Step 6.
1.Start
2.Set BaudRate
Key Inject
5.
Session Started
Key Inject
Receiving...
6.
Inject success.
Key Inject
Inject Success!
7.
Press the number
corresponding with your
selection.
1.Set to 1200 2.Set to 2400
3.Set to 4800
BaudRate 1200
4.Set to 9600
5.Set to 19200
8.
After setup the baud rate then start session to communication.
9.
Stop.

PAX S300 Specifications

General

Processor	32-bit ARM11
Security	PCI PTS 3.x approved
Card Readers	Magnetic Stripe, Contactless
Connectivity	RS232, USB, Ethernet
Memory	128MB Flash, 64MB SDRAM
