7 Camware Features
pco.edge User Manual V1.03 © PCO AG, Germany
35
Options: View Settings
Image Browser
Here you can select between showing all image tiles inside the browser
window either b/w or color. Setting b/w will result in a faster refresh. (valid
only for color CCD).
Marker
Use this command to display a cross in the centre or elsewhere in the
image (see "Set Crosshair" page 44).
Convert (Min/Max) (“Continuous Auto Range Crop”, see chapter 7.6 under
“Convert Control BW”)
This option enables the automatic min/max function during record and
replay. Disable this feature if the application stops responding during this
mode (due to operating system capacity problems).
Paint Images:
This option enables the update of (both double shutter images or) multiple
cameras images during record and replay. Disable this feature if the
application stops responding during this mode (due to operating system
performance problems).
Options: Toolbar
Toolbar
Opens the corresponding toolbars (see 7.2)
Math. Functions
With the math window you have the ability to build the difference between a
reference image and the actual image. If you activate math every new image
acquired will be subtracted from the reference image or vice versa.
last acquired image will be copied to reference buffer
a reference picture will be acquired and copied to reference buffer
add offset here to avoid negative values, which would not be visible
enable / disable math function
Replay Speed Bar
The faster replay speed is useful if large sets of image data need to be
scanned.
