Chapter 3 Installing Drivers for 6000 Boards
19
There are several functions to select, and the launch key is in brackets.
(e.g. press '2' key to do calibration)
Use <arrow key> (up/down) to select, and <Enter> to launch the
following functions:
(1) Draw
(2) Calibrate
(3) Detect
(4) Configure
(5) Packet
(6) Help
(7) Exit
2. Draw
Run the 'Draw' in PM2 Panel, and use the arrow keys or hot keys (A~Y)
to choose one of 25 video modes.
Video modes:
mode width height colors
0Dh 320 200 16
13h 320 200 256
10Dh 320 200 32K
10Eh 320 200 64K
10Fh 320 200 16M
0Eh 640 200 16
10h 640 350 16
100h 640 400 256
12h 640 480 16
101h 640 480 256
110h 640 480 32K
111h 640 480 64K
112h 640 480 16M
103h 800 600 256
113h 800 600 32K
114h 800 600 64K
115h 800 600 16M
105h 800 768 256
116h 1024 768 32K
117h 1024 768 64K
118h 1024 768 16M
107h 1280 1024 256
119h 1280 1024 32K
11Ah 1280 1024 64K
11Bh 1280 1024 16M
There are several function keys in the drawing screen:
[ESC] - exit
[Space] - clear screen and information
[F1] - help, list the function keys
[F2] - style, toggle line or dot.
