EasyTouch Control System User’s Guide
Settings Menu: Heat Pump COM (UltraTemp
®
Heat Pump)
Heat Pump Com screen
From the Heat Pump Com screen you can view the current UltraTemp® operation status, and set the unit to
operate with for heating only, cooling only, or both heating and cooling if the unit is reversible. Connection from
UltraTemp is via the COM PORT on the EasyTouch motherboard. See page 67 for UltraTemp to EasyTouch
COM port wiring information. The UltraTemp must be set to default ADDRESS 1. One UltraTemp unit can be
connected to EasyTouch.
Note: Once the UltraTemp is enabled, use the Left and Right arrow buttons to adjust the UltraTemp
temperature and cooling, (see page 3).
Heat Pump Com
To access Heat Pump Com (UltraTemp) settings menu:
Right button: Access the “Settings” menu.
Up/Down buttons: Select Yes or No to enable or disable UltraTemp.
Right button: Move to the “Heating” setting.
Up/Down buttons: Select Ye s or No to use for heating.
Right button: Move to the “Cooling” setting.
Up/Down buttons: Select Ye s or No to use for cooling only or if the unit is
reversible select both heating and cooling.
Press the Menu button to save the settings and to return to the Heat Pump Com
Settings and Status menu options.
Press the Menu button three times to return to the main screen.
To access Heat Pump Com (UltraTemp) Status menu:
MENU ▼ SETTINGS ▼ HEAT PUMP COM STATUS
Getting There
▲
Right button: To view the current UltraTemp status.
Press the Menu button to return to the main screen.
MENU ▼ SETTINGS ▼ HEAT PUMP COM SETTINGS
Getting There
▲
Status
[ OP NORMAL ]
<MENU> = EXIT
S
T
Settings
Status
T
S
X
Heat Pump Com
Enable : Yes
Heating : Yes
Cooling : Yes
Settings
Status
T
S
X
