50
EasyTouch Control System User’s Guide
Settings Menu: 10 Button Pump Cntrl
From this menu setting you can specify the IntelliFlo VS, VF and VSF pump speed (RPM, GPM) in step
increments, for the assigned iS4, iS10 or SpaCommand button using the “Pump Incrs” or “Pump Decrs” circuit
(see page 48 and 49). For example, the “Pump Incrs” and “Pump Decrs” circuit can be assigned to any two
iS10 buttons. Each press of the assigned “increase” button will increase the pump speed in specific speed
increments, as specified in the “iSx Pump Cntrl” menu setting. Speed increments are set from 10 to 250 RPM
or 1 to 10 GPM.
Assign iSx Pump Cntrl
Before setting the pump step speed, be sure to specify the IntelliFlo pump number and type in the IntelliFlo
menu (“Pump #1, Pump #2,” Pump Type), see page 32.
To set a pump step speed:
Up/Down buttons: Select the “Pump Number” as specified in the IntelliFlo menu
(see page 32).
Right buttons: Select the pump “Step” speed (RPM/GPM).
Up/Down buttons: Adjust the “Step” pump speed. Settings are:
- IntelliFlo VS: 10 to 250 RPM
- IntelliFlo VSF: 10 to 250 RPM or 1 to 10 GPM
- IntelliFlo VF: 1 to 10 GPM.
Press the Menu button to save the settings and to return to the Settings menu
options. Press the button twice to return to the main screen.
MENU ▼ SETTINGS ▼ 10B PUMP CNTRL
Getting There
▲
Spa Side Pump#1
IFlo Control
Step RPM: 060
Size
Spa Side Pump#2
IFlo Control
Step RPM: 060
Size GPM: 010
T
IS4
10 BUTN SPA SD
10B Pump Cntrl
Quick Touch
S
S
Pump #2: IntelliFlo VSF (RPM and GPM)
