EasyTouch Control System User’s Guide
Diagnostics Menu: Reset System
Reinitialize the Outdoor Control Panel. Resetting the Outdoor Control Panel will not effect the system
configuration settings.
Right button: Press the Right button to reset system. The main screen will be
displayed and communication will be established with the optional EasyTouch Indoor
Control Panel if installed.
Diagnostics Menu: Flash Update
Use this feature to update the EasyTouch Outdoor Control Panel firmware. The EasyTouch motherboard must
be connected to a personal computer (PC) in order to update the firmware.
Press the Menu button to exit the flash mode.
T
S
X
Air Temp
Disp codes
Cir Names [Off]
Reset System
MENU ▼ DIAGNOSTICS ▼ RESET SYSTEM
Getting There
MENU ▼ DIAGNOSTICS ▼ FLASH UPDATE
Getting There
Diagnostics Menu: Air Temp
Displays the current outside air temperature.
Press the Menu button to return to the Settings menu options. Press the button again
to return to the main menu options or press again to return to the main screen.
Diagnostics Menu: Cir Name: [Off/On]
This feature is useful if you have renamed many circuits and want to view the original factory default circuit
names.
To enable:
Right button: Select On to view the factory default circuit names.
Press the Menu button to exit.
To disable:
Right button: Select Off to disable the feature.
Press the Menu button to exit.
MENU ▼ DIAGNOSTICS ▼ AIR TEMP
Getting There
T
Air Temperature
72° F
S
T
Solar Temp
Air Temp
Disp codes
Cir Names [Off]
S
X
MENU ▼ DIAGNOSTICS ▼ CIR NAMES [OFF]
Getting There
