EasyTouch Control System User’s Guide
Settings Menu: QuickTouch (QT4) Wireless Remote
The QuickTouch QT4 wireless remote controller provides switching of up to four circuits. For example, you
can use the QT4 wireless remote to activate the spa circulation, and for operating three auxiliary pieces of
equipment (such as heat enabled, lights, jet pump, heat boost, air blower, waterfall, etc.).
Each of the four functions on the QT4 wireless controller has an on and an off button. To switch a circuit on
or off, press and hold the appropriate button for at least a full second.
The QT4 buttons can be assigned to any available circuit. However, the QT4 has the following preset circuits
assigned to the four buttons:
•Spa button activates the spa circuit.
•A button activates Auxiliary 1 circuit.
•B button activates Auxiliary 2 circuit.
•C button activates Auxiliary 3 circuit.
Assign QT4
To assign circuits to the QuickTouch wireless controller buttons:
Up/Down buttons: Select a circuit to assign to one of the QuickTouch wireless
remote buttons. You can set up to four circuits (1/4, 2/4, 3/4, 4/4).
Right button: Move to the circuit setting.
Up/Down buttons: To configure the first button (1/4) on the QuickTouch wireless
remote. Use these buttons to scroll through the circuit names and find the circuit that
you would like to assign to the first button. The generic circuits are: NONE, SPA,
POOL, AUX 1-7 (EasyTouch 8), AUX 1-3 (EasyTouch 4), FEATURE 1-8,
AUX EXTRA (or SOLAR if selected in “Heat” menu), HEAT BOOST and
HEAT ENABLED. Selecting “None” does not assign a circuit. “Aux Extra” is only
available if the Solar output (J17) plug on the EasyTouch motherboard is not being
used for solar equipment. Use the Solar button to switch the “extra” auxiliary circuit
on and off (see page 5).
Note: The “Heat Boost” feature will switch on the heater for seven minutes to
increase the spa water temperature. Each time the spa Heat Boost button is
pressed, the temperature will increase about 1
° F (-17° C). The temperature will
not go beyond the 104° F (40° C) limit.
Right button: Assign the next circuit (2/4).
Up/Down buttons: Select the first digit for the circuit number (1/4, 2/4, 3/4, 4/4),
then repeat the procedure for the other three buttons.
Press the Menu button to save the settings and to return to the Settings menu
options. Press the button again to return to the main menu options or press again to
return to the main screen.
MENU ▼ SETTINGS ▼ QUICKTOUCH ASSIGN QT4
Getting There
▲
S
Assign QT4
Circuit: 1/4
[SPA ]
T
