EasyTouch Control System User’s Guide
SELECT PUMP TYPE: Up/Down buttons: Choose VS, VF or VSF+SVRS.
Menu button: Press the MENU button to save selection and return to the selected
pump’s menu settings (see VS, VF and VSF pump settings descriptions below).
INTELLIFLO VS SPEEDS SETTING:
Down button: Choose Speeds.
Right button: Access the IntelliFlo VS speed (RPM) settings for Pump #1.
Up/Down button: Select the circuit number 1 of 8 (1/8).
Right button: Move to RPM to change the pump speed.
Up/Down buttons: Set speed of the pump from 400 to 3450 RPM in increments of
10 RPM. The default speed for each circuit correspond to the four speed buttons on
the IntelliFlo VS control panel is: Speed 1 button 750 RPM, Speed 2 button
1500 RPM, Speed 3 button 2350 RPM, and Speed 4 button 3110 RPM.
T
S
Pump #1 Type
Type: VS
Pump #1 1/8
RPM: 1200
Circuit:
[ POOL ]
T
T
Pump Type
Speeds
Priming
Status
X
T
S
INTELLIFLO VSF+SVRS FLOW RATE SETTING:
Down button: Choose Flow/Speeds.
Right button: Access the IntelliFlo VSF+SVRS speed (RPM/GPM) settings for
Pump #2.
Up/Down button: Select the circuit number 1 of 8 (1/8).
Right button: Move to GPM to change the pump flow rate.
Up/Down button: Select RPM or GPM. Press Up/Down button to toggle
between RPM and GPM and pressure setting (PSI).
Right button (GPM): Move to GPM pump flow rate.
Up/Down button: Set speed of the pump from 15 to 130 GPM. The default flow rate
is 30 GPM. The preset speed for each button is: Speed 1 button 1100 RPM (30
GPM), Speed 2 button 1500 RPM, Speed 3 button 2350 RPM, and Speed 4
button 3110 RPM.
Right button (GPM/PSI): Move to PSI (pounds per square inch) pressure setting.
Up/Down button: Select the pump pressure setting from 1 to 30 PSI. See above for
equivalent default RPM/GPM (speed/flow rate).
T
S
Pump #2 1/8
GPM:30 PSI: 15
Circuit:
[ NONE ]
T
T
Pump Type
Flow/Speeds
Status
X
T
S
Pump #2 Type
Type: VSF+SVRS
VS and VSF+SVRS CIRCUIT SETTING:
Right button: Move to the circuit names.
Up/Down buttons: Assign the pump circuit: NONE, SPA, POOL, AUX 1-7,
FEATURE 1-8 (EasyTouch 8), AUX 1-3 (EasyTouch 4), FEATURE
CIRCUITS C
1-8, AUX EXTRA (only if Solar is not selected, see page 46), HEATER,
POOL HEATER, SPA HEATER, FREEZE, POOL/SPA, and SOLAR/HEAT.
AUX EXTRA is only available if the Solar output (J17) plug on the EasyTouch
motherboard is not being used for solar equipment.
Right button: Press the Up arrow button and go to the next circuit page settings
(2/8) and repeat the previous steps.
When finished setting up the circuits, press the Menu button to save the settings and
to return to the Settings menu options. Press the button two times to return to the
main screen.
iS4/iS10/
SpaCommand spa-
side remote pump
speed control: T he
IntelliFlo pump speed
can be incrementally
increased or
decreased from the
spa-side remote. See
“10 B Pump Control”
in the “Settings” menu
(page 50).
Pump #2 1/8
GPM:30 PSI: 15
Circuit:
[ AUX 1 ]
T
T
IntelliFlo VS and VSF+SVRS Settings
INTELLIFLO VS STATUS SETTING:
Down button: Choose STATUS.
Right button: View the current VS status.
Menu: Press MENU to exit.
GPM: 30
1200 RPM 12 W
Watts: 10
Status: GOOD
T
T
