EasyTouch Control System User’s Guide
Settings Menu: 10 Button Spa-Side Remote Controller
From this menu you can assigning a specific circuit to any one of the ten buttons of an iS10 and SpaCommand
spa-side remote to control different pool/spa functions. The iS10 and SpaCommand has ten assignable circuit
buttons; five button on the top row and five buttons on the bottom row. You can also use the “Pump Incrs” and
“Pump Decrs” circuit to increase or decrease the pump speed for an IntelliFlo VF (GPM), VS (RPM) and
VSF (RPM/GPM) pump. For example, if the “Pump Incrs” circuit is assigned to an iS10 button, each press of
the button will increase the pump speed in specific speed increments as specified in the “10B Pump Cntrl”
menu setting (see page 50). Speed increments are set from 10 to 250 RPM (or 1 to 10 GPM, for the IntelliFlo
VF).
Assign 10 Button Spa Side Remote (iS10/SpaCommand)
Before configuring the 10 button spa-side remote controller (iS10/SpaCommand) assign names to the circuits
(see page 41).
To assign an iS10 and SpaCommand spa-side remote buttons:
Up/Down buttons: Select the “Top” or Bottom” row to assign circuits to.
Right buttons: Select a circuit to one of the iS10 buttons. Five top row buttons can
be assigned circuits (1/5, 2/5, 3/5, 4/5 and 5/5). See “iS10/SpaCommand button
assignments” below for details.
Right button: Move to the circuit setting.
Up/Down buttons: To configure the first button on the iS10 Spa-Side Remote, scroll
through the circuit names and find the circuit that you would like to assign to the first
button on the iS4. The generic circuits are: NONE, SPA, POOL, AUX 1-7
(EasyTouch 8), AUX 1-3 (EasyTouch 4), FEATURE 1-8, AUX EXTRA (or
SOLAR if selected in “Heat” menu), HEAT BOOST and HEAT ENABLED.
“Aux Extra” is displayed only available if the Solar output (J17) plug on the
EasyTouch motherboard is not being used for solar equipment. Use the Solar button to
switch the extra circuit on and off (see page 5). Selecting “None” does not assign a
circuit.
Note: The “Heat Boost” feature will switch on the heater for seven minutes to
increase the spa water temperature. Each time the spa Heat Boost button is
pressed, the temperature will increase about 1
° F. The temperature will not go
beyond the 104° F (40° C) limit.
Right button: Assign the next circuit (2/5).
Up/Down buttons: Select the first digit for the circuit number (1/5, 2/5, 3/5, 4/5) and
repeat the procedure for the other three buttons.
Press the Menu button to save the settings and to return to the Settings menu
options. Press the button twice to return to the main screen.
MENU ▼ SETTINGS ▼ 10 BUTN SPA SD ASSIGN 10 BUTN
Getting There
▲
1n o t t u B
APSLOOP
PME T - I HPME T - OL
2n o t t u B
1X U A5XUA
3n o t t u B
2X U A6XUA
4n o t t u B
3X U A7XUA
5n o t t u B
4X U A8XUA
iS10 and SpaCommand button assignments
T
Assign 10 BtnSS
Row : Top
Circuit : 1/5
[SPA ]
S
T
IS4
10 BUTN SPA SD
10B Pump Cntrl
Quick Touch
S
S
To Next Page
