Installer Manual
255/LOGIX 742
-762-764 - Syste
m sizing
28 / 92
Ref. MKT-IM-021 / A
- 20.02.2019
4.4.
Resin exchange ca
pacity upon
salt dosage for standard efficiency
Salt amount
Corresponding resin exchange capacity
grams /
liter of resin
grams /
liter of resin as CaCO
3
°f.m
3
/
liter of resin
°d.m
3
/
liter of resin
50
29.9
2.99
1.67
60
34
3.4
1.9
70
37.5
3.75
2.09
80
40.6
4.06
2.27
90
43.4
4.34
2.42
100
45.9
4.59
2.56
110
48.2
4.82
2.69
120
50.2
5.02
2.8
130
52.1
5.21
2.91
140
53.8
5.38
3.01
150
55.5
5.55
3.1
170
58.5
5.85
3.27
200
62.7
6.27
3.5
230
66.9
6.69
3.74
260
71
7.1
3.97
290
75.3
7.53
4.21
27
29
