6.4. Advanced programming (8-cycles softener system)
Note
Menus are displayed in a defined and incremental order.
Note
Press and hold + for 5 seconds to access advance programming. A "P" symbol is
displayed on the bottom left of screen.
The 742/762/764 features an advanced programming level that allows the installing dealer to make
changes to the controller for more demanding applications. The homeowner/end user should never
have to access this level.
The advanced programming menu includes:
* Calculated depending on salt setting and resin volume. The capacity may be manually adjusted.
Parameter description Range of values
Default
value
Units of
measure
Notes
P1 Time of day
1:00 - 12:59
AM/PM
0:00 - 23:59
12:00 PM
Hour:
minute
Range depends on value
selected for P10.
P2 Day of week - None N/A -
P3
Time of
regeneration
1:00 - 12:59
AM/PM
0:00 - 23:59
2:00 AM
Hour:
minute
Range depends on value
selected for P10.
P4
Days override
(Days between
regeneration on
742 controller)
0 - 99 0 Days
0 = no calendar override.
0.5 = regeneration twice a day
at time of regeneration and
12 hours later.
P5
Day of week
regeneration
- None N/A
Day of week regeneration is
skipped if calendar override is
more than 0 (742 controller
only).
P6 Salt amount 50 - 290 110 g/l
Unit of measure depends on
value selected for P9.
P7 System capacity 0.1 - 90 * kg
Unit of measure depends on
value selected for P9.
P8 Water hardness 30 - 2000 250 mg/l
Unit of measure depends on
value selected for P9
(762 - 764 controllers only).
