Installer Manual 255/LOGIX 742-762-764 - Programming
56 / 92 Ref. MKT-IM-021 / A - 20.02.2019
6.6. Diagnostic
Press and hold and for 5 seconds, diagnostic H symbol is displayed on the bottom left of the
screen.
Diagnostic
Code
Description Unit Range 742 762 764
H0 Initial setting value Litre
Resin
Volume
Yes
Yes
Yes
H1 Days since last regeneration Days 0 - 255
H2 Current flow rate Depends on turbine used
No
H3
Water used today since time of
regeneration
m
3
0 - 1310.70
H4 Water used since last regeneration
m
3
0 - 1310.70
H5 Total water used since reset in 100 s
m
3
0 - 9999
H6
Total water used since reset in
1000000 s
m
3
4264 x 10
4
H7 Average usage for Sunday
m
3
0 - 1310.70
H8 Average usage for Monday
m
3
0 - 1310.70
H9 Average usage for Tuesday
m
3
0 - 1310.70
H10 Average usage for Wednesday
m
3
0 - 1310.70
H11 Average usage for Thursday
m
3
0 - 1310.70
H12 Average usage for Friday
m
3
0 - 1310.70
H13 Average usage for Saturday
m
3
0 - 1310.70
H14 Average service cycle Day 0 - 255
H15 Peak flow rate l/min 0 - 1000
H16 Day and time of peak flow rate
Time and day that peak
flow occurred
H17 Months since service Months 0 - 2184 Yes
H18
Water used since last regeneration -
tank 1
m
3
0 - 1310.70
No No
H19
Water used since last regeneration -
tank 2
m
3
0 - 1310.70
Hr
Number of regenerations since last
service
N/A 0 - 65536 Yes
Yes
