Pentair Logix 762 Installer Manual

Installer Manual 255/LOGIX 742-762-764 - Programming
54 / 92 Ref. MKT-IM-021 / A - 20.02.2019
* Default value selected with valve type and resin volume.
** Factory default value is "0" for North America Made and "1" for European Made.
P18 Flow sensor select 0 - 7 * N/A
762/764 controllers only:
0 = internal turbine,
Magnum IT NHWB.
1 = 1" Autotrol turbine,
2 turbines per system.
2 = 2" Autotrol turbine,
2 turbines per system.
3 = User defined K-factor.
4 = User defined pulse
equivalent.
5 = Magnum IT HWB.
764 controller only:
6 = 1" Autotrol turbine,
1 turbine per system, available
with Alternating systems only.
7 = 2" Autotrol turbine,
1 turbine per system, available
with Alternating systems only.
P19
K-factor or
pulse equivalent
1.00 -99.99
1 - 9999
0.01
1
N/A
762/764 controllers only:
K-factor P18 = 3.
Pulse equivalent P18 = 4.
Pr Refill first 0 - 1 0 N/A
0 = Refill first off
1 = Refill first on
(not used with Alternating
system)
Pd
Regeneration
mode when
initiated by a
remote signal
0 - 1 0 N/A
742/764 controllers only:
0 = Immediate regeneration
1 = Delayed regeneration
Parameter description Range of values
Default
value
Units of
measure
Notes
