Installer Manual 255/LOGIX 742-762-764 - Spare parts
Ref. MKT-IM-021 / A - 20.02.2019 83 / 92
Item Part number Description
Assembly
quantity
1 1244650 255 valve assy with out flow controls 1
2 1033784 255 tank adapter new style 1
3 1010154 O-Ring EP, tank 1
4 1232370 O-Ring EP, riser tube 1
5 1235340 Top plate, 255 valve, 700/860 series 1
6 1235341 Spring, one-piece, 255 valve 1
7 1236246 Cover, valve, 255/Performa, 700/860 1
* 1267672 Slim line cover 255 700/800 1
8 1001404 O-ring group: tank adapter 1
9 1040459 O-Ring group: piping boss 1
10 1001986 13/16" rubber insert (optional) 1
* 1000250 Valve disk kit - standard/sev 1
* 1239760 Blending valve kit 400 & 700 series 1
11 1031402 Multilingual language locking bar 1
12 1234170 Locking bar screw no 8-9/16 1
13
1235353
Camshaft 255/700-860 series std black for single systems L
mode
1
1236251
Camshaft 255/700-860 series twin tan for twin versions A + P
mode
1
14 1238861 Motor + cable 700 series controller, 12 V 50/60 Hz 1
* 3029962 Motor locking pin (white) 1
15 1000226 Screen/cap assy with o-ring 1
16
1035730 “E” inj (high efficiency) - yellow (6" dia. vessels) 1
1035731 “F” inj (high efficiency) - peach (7" dia. vessels) 1
1035732 “G” inj (high efficiency) - tan (8" dia. vessels) 1
1035733 “H” inj (high efficiency) - lt purple (9" dia. vessels) 1
1035734 “J” inj (high efficiency) - lt blue (10" dia. vessels) 1
1035735 “K” inj (high efficiency) - pink (12" dia. vessels) 1
1035736 “L” inj (high efficiency) - orange (13 - 14" dia. vessels) 1
17 1000269 Inj cap with o-ring 1
18
1000208 Drain control assy with o-ring No.6 1
1000209 Drain control assy with o-ring No.7 (1.2 gpm; 4.5 Lpm) 1
1000210 Drain control assy with o-ring No.8 (1.6 gpm; 6.1 Lpm) 1
1000211 Drain control assy with o-ring No.9 (2.0 gpm; 7.6 Lpm) 1
